High Speed 0.4m/s Insulated Sectional Overhead Door 42mm PU Sandwich Panel R-Value 13.73 Energy Efficient
उत्पाद विवरण:
| उत्पत्ति के प्लेस: | चीन |
| ब्रांड नाम: | DESEO |
| प्रमाणन: | CE/ISO9001:2008 |
| मॉडल संख्या: | एसडी6100 |
भुगतान & नौवहन नियमों:
| न्यूनतम आदेश मात्रा: | 1 इकाई |
|---|---|
| मूल्य: | USD 850-1200/UNIT |
| पैकेजिंग विवरण: | सुरक्षात्मक फिल्म के साथ प्लाईवुड पैकेज |
| प्रसव के समय: | 10-25 दिन |
| भुगतान शर्तें: | टी/टी, एल/सी |
| आपूर्ति की क्षमता: | प्रति माह 200 यूनिट |
|
विस्तार जानकारी |
|||
| सामग्री: | जस्ती इस्पात, एल्यूमीनियम मिश्र धातु | पैनल की मोटाई: | 42एमएम |
|---|---|---|---|
| पैनल की चौड़ाई: | 500 मिमी | मूल सामग्री: | पॉलीयुरेथेन फोम 48 किग्रा/एम3 |
| आर-मूल्य: | 13.73 | ओपनिंग स्पीड: | 0.4m/s |
| संचालन: | इलेक्ट्रिक, रिमोट, मैनुअल | ऊष्मा परिरक्षण: | 4.5W/mh |
| पवन प्रतिरोध: | ब्यूफोर्ट स्केल 11, 28 मी/से | ध्वनि इंसुलेशन: | 24 डीबी |
| अग्निशमन: | एक कक्षा | सेवा जीवन: | 10 वर्ष |
| अधिकतम आयाम: | 12मी x 8मी | सतह का उपचार: | पाउडर कोटिंग 30um |
| आवेदन: | औद्योगिक, गोदाम, गेराज, वाणिज्यिक | ||
| प्रमुखता देना: | High Speed 0.4m/s Insulated Sectional Door,42mm PU Sandwich Panel Overhead Door,Energy Efficient R-Value 13.73 Sectional Door |
||
उत्पाद विवरण
Energy Efficient High Speed Insulated Sectional Overhead Door
The SD6100 insulated sectional overhead door combines rapid 0.4m/s opening speed with industry-leading thermal performance. Designed for high-traffic industrial and commercial environments where both speed and energy efficiency are critical.
Key Features
- Industry-Leading R-Value 13.73: 42mm polyurethane foam sandwich panels deliver exceptional thermal insulation, reducing HVAC costs and maintaining stable indoor temperatures year-round.
- 0.4m/s High Speed Operation: Minimizes air exchange and heat loss during frequent open/close cycles, ideal for busy logistics centers and loading docks.
- 48kg/m3 High Density PU Core: Superior structural rigidity with excellent noise dampening at 24 dB sound insulation.
- Class A Fire Retardation: Meets stringent fire safety standards for industrial facilities.
- Beaufort 11 Wind Resistance: Engineered to withstand wind speeds up to 28m/s for exposed installations.
Technical Specifications
| Material | Galvanized Steel, Aluminum Alloy, Color Coating Plate |
| Panel Thickness | 42mm |
| Panel Width | 500mm |
| Core Density | 48kg/m3 Polyurethane Foam |
| R-Value | 13.73 |
| Opening Speed | 0.2-0.4m/s |
| Guide Rail Thickness | 2mm Galvanized Steel |
| Surface Treatment | Powder Coating 30um |
| Heat Preservation | 4.5W/m.h |
| Sealing | EPDM Rubber All-Round Sealing |
| Max Dimension | 12m x 8m |
| Power Supply | 380V 50Hz / 220V 50Hz |
| Service Life | 10 years / 100,000 cycles |
| Emergency Operation | Manual Hoist Chain |
Safety Systems
- Finger-protection (pinch-resistant) panel joint design
- Airbag safety edge for obstacle detection
- Door anti-fall device
- Wire rope anti-break protection
- Torsion spring balance system with spring brake device
Applications
Ideal for logistics warehouses, distribution centers, manufacturing plants, automotive workshops, and commercial garages where high-traffic access and thermal efficiency are priorities.
